The Organ
Specification
The following is a transcript of the stoplist given in Hill's Shop Book:
Pedal F (9 stops) | Choir C (7 stops) | Great C (9 stops) | Swell C (14 stops) |
---|---|---|---|
Acoustic 32 | Gamba 8 Full Tone | Double Open Diapason 16 No. 2 | Double Diapason 16 (Bdn.) |
Open 16 | Dulciana 8 | Open Diapason ii 8 | Open Diapason 8 |
Violone 16 No 8 | Leiblich Gedact | Open Diapason iii 8 | Gamba 8 (string tone) |
D. Dul 16 No 9 | Lieblich 4 (Gems. crossed out) | Hohl Flute 8 | V. Cel. 8 (C) (string tone) |
Bourdon 16 | Suabe Flute 4 | Principal 4 | Dolce 8 (Dul tone) |
Octave 8 | Harmonic Piccolo 2 | Fifteenth 4 | Unda Maris 8 (C) (Dul tone) |
Bass Flute 8 | Clarinet 8 | Mixture iii (17 19 22) | Rohr Flute 8 |
Cello 8 | Sw. to Ch. | Tromba 8, 6” | Principal 4 |
Trombone 16, 6” | Tremulant | Open i 8, 6” | Fifteenth 2 |
4 Pedal Couplers | Sw. to Gt. | Mixture iii (17 19 22) | |
Solo C (4 stops) | Solo to Gt. | Oboe 8 | |
Harmonic Flute 8 (not loud) | Contra Fagotto 16, 6” | ||
Harmonic Flute 4 (not loud) | Horn 8, 6” | ||
Orchestral Oboe 8 B flat | Clarion 4, 6” | ||
Tuba 8, 10” | Swell Octave | ||
Solo Sub Octave | Swell Sub Octave | ||
Solo Octave | Tremulant |
- General wind 3¼”
- 4 pistons to Solo
- 4 pistons to Great (& Ped)
- 4 pistons to Swell
- 4 pedals to Swell
- 1 pedal poppet for Great to Ped (draw on each side)
- Electric Blowing - Feeders. No hand blowing
- (rotary blower installed some time in the 60s/70s)
- the Orchestral Oboe is, in fact, full compass
